HERMETIC SEALED HPCL SLIDING DOOR

DOORS

Door Type: Sliding

Mechanism:

Manual

Automatic

Product Code: HSHSD

The HERMETIC SEALED HPCL Sliding Door is a high-performance solution designed for controlled environments that require airtight sealing, hygiene, and durability. Made using High-Pressure Compact Laminate (HPCL), the door is both moisture-resistant and impact-resistant, making it ideal for cleanrooms, hospitals, pharmaceutical facilities, and laboratories.

Key Features:

Hermetic Sealing System
Specially designed track and pressure-drop mechanism ensure airtight closure, minimizing contamination and maintaining pressure integrity.
HPCL Door Panel
Manufactured using High-Pressure Compact Laminate that is robust, hygienic, and resistant to chemicals and cleaning agents.
Manual or Automatic Operation
- Manual Version: Smooth, low-friction sliding mechanism for effortless operation.
- Automatic Version: Sensor-based, hands-free operation for seamless entry/exit and improved infection control.
Silent & Smooth Movement
Engineered to function with minimal noise—suitable for sensitive medical and sterile environments.
Flush Finish & Easy Cleaning
Flat surfaces and concealed hardware support easy maintenance and compliance with cleanroom standards.

The hermetically sealed HPCL (High Pressure Compact Laminate) sliding door. It can be made of single leaf as well as double leaf. The door is developed specially for operation theaters and sterile areas. Normally an operation theater runs on over pressure. At this pressure any leakage losses will still not be measurable due to the hermetic sealing property of the door.

Core of the door blade is 60mm thick and has 4mm thick without joint premium grade High Pressure compact laminates on both side of 52mm thick injected polyurethane. This door core is framed with extruded aluminum profiles finished with natural anodizing. Smart radius and curves on the edges makes the door cleaning very easy.

Specially designed lever opener made out of solid stainless steel is there to ensure effortless opening and closing of the door. The door blade comes with toughed glass sandwich vision window, flushed with both side core surfaces of the door. Special Design of 3 tier EPDM sealing gasket to seal the aluminum wall frame and 2 tier bottom gasket fixed on the lower part of door blade to ensure perfect hermetic sealing with finished floor.

Applications:-
