HERMETIC SEALED SS.304 SLIDING DOOR

DOORS

Door Type: Sliding

Mechanism:

Manual

Automatic

Product Code: HS304SD

The HERMETIC SEALED S.S. 304 Sliding Door is engineered for critical environments requiring airtight integrity, hygiene, and durability. Constructed from premium-grade Stainless Steel 304, this sliding door system ensures long-lasting performance in high-sterility zones such as hospitals, cleanrooms, pharmaceutical units, and laboratories.

Key Features:

Hermetic Sealing Technology
Precision-engineered sealing system ensures airtight closure, preventing air leakage, cross-contamination, and maintaining pressure differentials.
S.S. 304 Construction
Corrosion-resistant and non-porous stainless steel makes it ideal for hygienic, sterile, and moisture-prone environments.
Manual or Automatic Options
- Manual: Smooth, frictionless sliding with ergonomic handle design.
- Automatic: Sensor-activated, touchless operation for hands-free access and hygiene compliance.
Silent Operation
Smooth and quiet motion designed for patient care areas and sensitive lab settings.
Hygienic & Easy to Maintain
Flush-mounted design with seamless finish supports frequent cleaning and sanitation.

The hermetically SS.304 (Stainless Steel) sliding door. It can be made of single leaf as well as double leaf. The door is developed specially for operation theaters and sterile areas. Normally an operation theater runs on over pressure. At this pressure any leakage losses will still not be measurable due to the hermetic sealing property of the door.

Core of the door blade is 60mm thick and has 1mm thick without joint premium grade SS.304 sheet on both side of 58mm thick injected polyurethane. This door core is framed with extruded aluminum profiles finished with natural anodizing. Smart radius and curves on the edges makes the door cleaning very easy.

Specially designed lever opener made out of solid stainless steel is there to ensure effortless opening and closing of the door. The door blade comes with toughed glass sandwich vision window, flushed with both side core surfaces of the door. Special Design of 3 tier EPDM sealing gasket to seal the aluminum wall frame and 2 tier bottom gasket fixed on the lower part of door blade to ensure perfect hermetic sealing with finished floor.

Applications::-
